BQ FibreLineBuildQuote

BQ FibreLine

BQ FibreLine VGroove Panel

Cladding · Fibre cement vertically grooved cladding panel

BQ FibreLine VGroove Panel is a pre-primed fibre cement cladding sheet with machined vertical V-grooves at regular intervals.

Select colours and profiles to add them to your shopping list.

Select colour

Profile

Main profile133mm VGroove
Specs2400mm × 900mm × 9mmPart noBQ-FL-VGP-133-2400UOMsheet
Additional profile200mm VGroove
Specs2400mm × 900mm × 9mmPart noBQ-FL-VGP-200-2400UOMsheet

Description

BQ FibreLine VGroove Panel is a pre-primed fibre cement cladding sheet with machined vertical V-grooves at regular intervals. Produces a modern linear vertical appearance when installed. Available in 133mm and 200mm groove spacings. Fix vertically to horizontal batten framing.

Performance

Moisture resistantBAL All levelsAustralian made1 colourway

Notes

Pre-primed and ready for site painting.

Installation guide · buildquote.com.auInstallation guideDesign guide · buildquote.com.auDesign guideWebsite · buildquote.com.auBQ FibreLine website

1

Primers

BQ FibreLine Cut End Sealer 250mLPenetrating acrylic end-grain sealer for treating all cut edges of BQ FibreLine fibre cement products. Prevents moisture ingress at cut ends. Brush apply two coats. Required at all cut ends prior to installation.
Specs—Part noBQ-FL-ENDSEAL-250MLUOMtin
2

Trims & Flashings

BQ FibreLine Aluminium Jointer Bead 3000mmExtruded aluminium H-section jointer bead for open-joint installation of BQ FibreLine Flat Sheet and VGroove panels. Accepts 9mm sheet thickness each side. Mill finish - field-paintable. Includes factory-applied foam backing strip.
Specs—Part noBQ-FL-JOINTER-AL-3000UOMlength
3

Fasteners

BQ FibreLine FC Nail 30mm x 2.8mm 1kgHot-dipped galvanised clout nail for face-fixing BQ FibreLine fibre cement products to timber framing. 30mm length, 2.8mm shank, flat head. Also suitable for pneumatic nail gun installation.
Specs—Part noBQ-FL-NAIL-30MM-1KGUOMbag
4

Sealants

BQ FibreLine FC Joint Sealant 300mLPaintable, flexible polyurethane joint sealant for sealing butt joints, cut ends and penetrations in BQ FibreLine fibre cement products. Adheres to primed FC surfaces without primer. Overpaintable after 24 hrs.
Specs—Part noBQ-FL-SEALANT-300MLUOMbox
